Adjustable flanges can be used to adjust the distance and angular relationship between two flanges. This product uses CF standard flange, and each model can provide an adjustment range of ±5mm in the axial direction and ±3° in the radial direction.

• Mounted in any orientation
• Working Pressure: 10-11 mbar~1 bar
• Bakeable to 200℃
• Welded Bellows Seal with SS 316
• Clear Hole Flanges on Both Sides
• Angular tilt: ±3°
• Axial Adjustment: ±5 mm

This system is used to deposit layers under high vacuum conditions on samples that are RF biased. It is a low temperature technique when compared to typical CVD process, which is a major advantage.

Core System Features:
• Base Pressure 1.10-6 mbar
• Samples up to 300 mm
• Inferior plate of 500 mm diameter with RF bias
• Various Process gases (TMS, Hexane, CF4, O 2, Ar)
• Pumping group (Suitable for corrosive gases)
• Automated Control

Applications:
• Barrier Films
• Insulators
• Optical coatings
• Biomedical

Materials:
• DLC
• Doped/Undoped Amorphous Si
• Dielectrics (Nitrides, Oxynitrides..)

Synthesis of complex materials & crystalline structures is a constantly growing request from research. Pulsed Laser Deposition (PLD) is one answer. It is a versatile coating technique that allows the growth of various materials such as nitrides, oxides, superlattices, polymers and composites etc.

Using years of comprehensive experience and know how in R&D deposition systems and ultra high vacuum technology, Vinci Technologies has designed a Laser deposition system, which is easy to operate and designed for academic & industrial researchers alike.

Advantages:
• Flexible & evolving
• Full supervision
• Cost effective

Main features:
• Thin film growth of complex materials
• UHV
• Oxygen-resistant 950°C 1’’ sample holder
• Adjustable distance from substrate to target
• Combinatorial deposition
• RHEED as option
• 10-8 mbar chamber
• 10-9 mbar with load-lock
• Regulated upstream/downstream pressure control
• Transferable 1-inch substrate holder
• Ports for in-situ characterization
• Reactive or Pulsed Laser Deposition capability
• 8-position target holder
• Turbomolecular pumping
• Optional load lock chamber

Synthesis of complex materials & crystalline structures is an ever growing request from research & development. The Pulsed Laser Deposition (PLD) technique provides an intelligent solution for such requirements. It is a versatile coating technique that allows the growth of various materials such as nitrides, oxides, super lattices, polymers and composites etc.

With over 30 years experience in vacuum and UHV, Vinci Technologies provides tailored solutions to customer requirements with this laser-MBE system. This configuration adapts to a large field of growth parameters. For example, process pressure ranges from 10-10 to hundreds of mbar.

Flexible and evolving, this PLD equipment consists of a chamber with ports for process and characterization.

This system is compatible with 2-inch samples. The UHV & dry pumping design prevent the deposited films from contamination by external sources of pollution.

Samples can be transferred from a load-lock chamber or MECATRANS™ UHV transfer tunnel.

Applications:
• Thin film growth for stoichiometric films of complex compounds

Primary Features:
• Reactive or UHV Pulsed Laser Deposition capability
• RF plasma source
• 5-axis target holder (4 targets or 8 upon request)
• Transferable 2-inch substrate and target holders
• Oxygen-resistant 950°C 2’’ sample holder
• 10-10 mbar chamber
• Turbo molecular, ion & titanium sublimation pumping
• Ports for in-situ characterization
• High pressure RHEED
• Quick maintenance of laser window
• Load lock chamber
• Transfer tunnel compatibility
• Evolutionary system

CF Nut Bolt and Washers with Silver Plated Bolts are used to clamp two flanges together and compress them against the copper gasket creating a vacuum seal for applications involving baking. The silver plating allows for easy disassembly after baking.

Manufactured from: Stainless Steel and Silver Plating. CF Nut Bolt and Washer (Silver Plated Bolts) sets are supplied in sealed plastic bags.

CF Nuts, Bolts and Washers (Silver Plated Bolts) are manufactured to the ISO standard and are compatible with other supplier’s products.

CF Nut Bolt and Washers with Silver Plated Bolts are used to clamp two flanges together and compress them against the copper gasket creating a vacuum seal for applications involving baking. The silver plating allows for easy disassembly after baking.

Manufactured from: Stainless Steel and Silver Plating. CF Nut Bolt and Washer (Silver Plated Bolts) sets are supplied in sealed plastic bags.

CF Nuts, Bolts and Washers (Silver Plated Bolts) are manufactured to the ISO standard and are compatible with other supplier’s products.

CF Nut Bolt and Washers with Silver Plated Bolts are used to clamp two flanges together and compress them against the copper gasket creating a vacuum seal for applications involving baking. The silver plating allows for easy disassembly after baking.

Manufactured from: Stainless Steel and Silver Plating. CF Nut Bolt and Washer (Silver Plated Bolts) sets are supplied in sealed plastic bags.

CF Nuts, Bolts and Washers (Silver Plated Bolts) are manufactured to the ISO standard and are compatible with other supplier’s products.

CF Nut Bolt and Washers with Silver Plated Bolts are used to clamp two flanges together and compress them against the copper gasket creating a vacuum seal for applications involving baking. The silver plating allows for easy disassembly after baking.

Manufactured from: Stainless Steel and Silver Plating. CF Nut Bolt and Washer (Silver Plated Bolts) sets are supplied in sealed plastic bags.

CF Nuts, Bolts and Washers (Silver Plated Bolts) are manufactured to the ISO standard and are compatible with other supplier’s products.

CF Nut Bolt and Washers with Silver Plated Bolts are used to clamp two flanges together and compress them against the copper gasket creating a vacuum seal for applications involving baking. The silver plating allows for easy disassembly after baking.

Manufactured from: Stainless Steel and Silver Plating. CF Nut Bolt and Washer (Silver Plated Bolts) sets are supplied in sealed plastic bags.

CF Nuts, Bolts and Washers (Silver Plated Bolts) are manufactured to the ISO standard and are compatible with other supplier’s products.

PVD-4 is a physical vapor deposition system, dedicated to the evaporation or sputtering deposition process of materials. Its evolutionary design is particularly adapted to laboratory requirements in terms of everyday applications, as its simplicity to use and its competitive price.

Deposition techniques include:
• Thermal & EBeam Evaporation
• Magnetron Sputtering
• Hybrid Configuration
• Organic Configuration

Core System Features:
• Stainless Steel – 320 mm diameter cylindrical
• Fast Entry Frontal Door with viewport
• Sample holder for substrates up to 4” in diameter
• Water cooling to avoid excess heating

The PVD-6 is a physical vapor deposition system, dedicated to the sputtering deposition process of materials. Its evolutionary design is particularly adapted to laboratory requirements in terms of everyday applications, as its simplicity to use and its competitive price.

Core System Features:
• Stainless Steel – 500 mm diameter cylindrical
• Fast Entry Frontal Door with viewport
• Sample holder for substrates up to 6” in diameter
• Water cooling to avoid excess heating

The PVD20-EB is a physical vapor deposition system, dedicated to the electron beam deposition process of materials. Its evolutionary design is particularly adapted to laboratory requirements in terms of everyday applications, as its simplicity to use and its competitive price.

Core System Features:
• D-shape steel – 500 mm diameter cylindrical chamber
• Full access frontal door with 2 viewports for easy maintenance
• Sample holder for substrates up to 6” in diameter
• Rotating and water cooled substrate holder
• Water cooling to avoid excess heating
• Secured cryo pumping group

E-Beam Evaporation:
• 8X8 cc or 6X7 cc electron beam source (Ti, Au, Ag, Al, Cr, W, Pt)
• Power supply from 3 kW to 12 kW
• Gas panel for Ar, O2, N2
• Accurate control of deposition rates
• Loadlock (option)
• RF plasma pre-cleaning (option)

The PVD20-S is a physical vapor deposition system, dedicated to the sputtering deposition process of materials. Its evolutionary design is particularly adapted to laboratory requirements in terms of everyday applications, as is its simplicity to use and its competitive price.

Core System Features:
• D-shape steel – 500 mm diameter cylindrical
• Full access frontal door with 2 viewports for easy maintenance
• Sample holder for substrates up to 6” in diameter
• Rotating and heating (up to 350°C) substrate holder
• Water cooling to avoid excess heating
• Secured cryo pumping group (option)
• Loadlock (option)
• RF plasma pre-cleaning (option)

Sputtering Process:
• Up to 4 x 3-inch cathode magnetrons in Sputter Up configuration
• RF / DC power supply
• Process pressure: 10-3 – 10-1 mbar with a motorized throttle valve
• Up to 8 cathodes in sputter up configuration
• Gas panel for Ar, O2, N2
• Accurate control of deposition rates (crystal sensor)

The PVD20-TE is a physical vapor deposition system, dedicated to the joule heating deposition process of materials. Its evolutionary design is particularly adapted to laboratory requirements in terms of everyday applications, as is its simplicity to use and its competitive price.

Core System Features:
• D-shape steel – 500 mm diameter cylindrical
• Full access frontal door with 2 viewports for easy maintenance
• Sample holder for substrates up to 6” in diameter
• Rotating and heating (up to 350°C) substrate holder
• Water cooling to avoid excess heating
• Secured cryo pumping group (option)
• Loadlock (option)
• RF plasma pre-cleaning (option)

Thermal Evaporation Process:
• Evaporation by joule effect
• Up to 4 sources (boats, rods, baskets, filament, crucibles)
• Cross contamination shields included
• DC power supply with temperature regulation
• End Hall Effect pre clean/deposition assist
• Gas panel for Ar, O2, N2
• Accurate control of deposition rates (crystal sensor)

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium Leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium Leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available

CF to ISO Tubulated reducing adaptors are used to change from a CF flange to an ISO mating flange enabling the fitting together of mismatched components.

Manufactured from: 304L Stainless Steel. Helium Leak tested to 10-10 mbar. They are supplied in a plastic bag with protective plastic caps.

The CF to ISO Tubulated Adaptors are manufactured to the CF and ISO Standards and are compatible with other supplier’s product.

• Material: 304L Stainless Steel
• Bakeable to 150°C
• Vacuum Rating 1×10-11 mbar
• Wide range of elbows, crosses, tees and adaptors are available
